Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm
  • Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm
  • Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm
  • Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm
  • Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm
  • Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm

Z40~Z275 G/㎡ DX51D+Z Prepainted / PPGI / Z60g Color Coated Steel Coil 0.20-1.70mm

Product Details
Application:
Electric Power And Other Industries
Materials Grade:
DX51D
Thickness:
0.60mm BMT
ZINC:
Z180 G/sqm
Paint Coating:
25 Micron μm
Paint System:
HDP
Paint Brand:
VALSPAR
Highlight:

Z60g Color Coated Steel Coil

,

Color Coated Steel Coil 1.70mm

,

Z275 PPGI Steel Coil

Payment & Shipping Terms
Minimum Order Quantity
16 MT
Price
1000 USD/MT
Packaging Details
Standard Exporting Package with Wooden Pallet
Delivery Time
30-40 DAYS
Payment Terms
L/C, T/T
Supply Ability
500MT/DAY
Product Description

Z40~Z275 G/㎡ DX51D+Z Color Prepainted Steel PPGI / Color Coated Steel PPGI / Z60g Steel Coil Base Metal 0.20-1.70mm

DECHO building colour steel plate can meet the need to use colour steel plate as raw material for building. DECHO BUILDING MATERIALS colour steel plate is mainly processed into, for example, colour steel corrugated board or colour steel composite sandwich board after our colour steel plate is widely used in the construction of airports, freezers, steel plants, warehouses, and other industrial buildings and commercial buildings, such as the roof of the colour steel tiles, colour steel plate sandwich walls and doors.

HDP high durability colour coating board adopts HDP polyester coating, good durability, adopts high molecular weight resin, the polymer branch chain is less, the bond energy is stable, not easy to photolysis so it is not easy to chalking, the gloss degree decreases to a high level.

HDP colour steel plate at the same time adopts the inorganic ceramics pigment, it is not easy to fade in the sunlight.

The most important performance of high weather resistance polyresin is high weather resistance and strong corrosion resistance, mainly used for long sunshine time, high dryness, or large temperature difference between day and night, humidity strong more harsh areas.

Wide range of uses. It belongs to the high-end products of colour coated sheet and coil.

The coating thickness is generally 5UM epoxy resin primer + 20UM HDP polyester top coat on the front side, and 5UM epoxy resin primer + 6UMPE resin top coat on the reverse side.HDP high weathering colour coated sheet rolls can be provided with a 15-year quality assurance certificate to ensure that the coating does not fall off, no chalking, cracking, and no fading within 15 years.



Scope of application

Because of its good corrosion resistance and UV resistance, HDP high weathering colour coated sheet is mainly used in chemical, metallurgy, electric power and other industries with high requirements for UV and corrosion resistance, as well as in areas with high salt fog and high altitude.

Reasons for choosing us:

  1. Provide extremely rich colour choices

  2. The paint surface is long-lasting and bright

  3. Surface coating will not fall off after stamping and has good hardness with strong ductility and is not easy to scratch.

  4. with excellent weather resistance, corrosion resistance, is to ensure the durability of the premise of the building

  5. DECHO BUILDING MATERIALS for the manufacturer direct sales

  6. The colour is customized by customers;

  7. Thickness and width have a variety of options;

  8. We provide whole rolls and cut boards for sale;

Index

Pre-Painted Galvanized/ Galvalume / Aluminum Sheets & Coils

Thickness

Base Metal : GI: 0.20-1.70mm; GL: 0.20-1.50mm

Base Metal: Aluminum 0.30-3.0mm

Width

600~1500mm

Zinc Coating

Z40~Z275 g/㎡

AZ30~AZ200 g/㎡

Paint Structure

2/1, 2/2, 3/2, 3/3

Paint Coating

Top side: 15μm~55μm

Back side: 5μm~30μm

Paint System

RMP, PE, SMP, HDP, PVDF

Paint Brand

PPG

Beckers

AkzoNobel

Valspar (Sherwin-Williams)

Chinese local brands

Paint surface

Gloss RAL color system

Textured/Matt/Wrinkle Surface

Printch Pattern Colors-Wood, Brick, Stone grains.

Coil weight

2 ~ 10 tons

Packing

Standard export packing ( Eye to Side)

Vertical Packing ( Eye to Sky) with wooden pallet

Horizontal Packing ( Eye to Side) with wooden pallet

MOQ.

16 tons/color/size
