0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
  • 0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019
0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019

0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019

Place of Origin China
Brand Name Decho Building Materials
Certification MILL TEST CERTIFICATE
Model Number S320GD PPGI
Product Details
Paint Surface:
Customised Patterns
Thickness:
0.50~1.2mm
Width:
1000~1250mm
Steel Grade:
DX51D
PAINT SYSTEM:
HDP/ Super-SMP/PVDF
Paint Brand:
Chinese Local Paint Brand
Payment & Shipping Terms
Minimum Order Quantity
25 TONS
Price
USD 780~1050
Packaging Details
Standard Exporting Packing(Eye to Side) , No pallet Vertical Packing (Eye to Sky) with Wooden Pallet, Horizontal Packing (Eye to Side) with Wooden Pallet
Delivery Time
30~45days
Payment Terms
L/C, T/T
Supply Ability
500 tons per day
Product Description

0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil

PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019



Product details:

PPGI & PPGL (prepainted galvanized steel & prepainted galvalume steel) also known as pre-coated steel or color coated steel coil, It is a product made of hot-dip galvanized steel sheet, hot-dip galvalume steel sheet, electro galvanized steel sheet, etc.

After surface pretreatment, one or several layers of organic coating are applied on the surface, and then baked and solidified. The color coated steel coil is light in weight, beautiful in appearance, and has good anti-corrosion performance, and can be directly processed. The color is generally divided into gray, sea blue, brick red, etc. It is mainly used in advertising, construction, decoration, home appliances, electrical appliances, Furniture industry and transportation industry. The coatings used for color coated steel coils are based on the environment in which the resin is selected, such as polyester silicon modified polyester, polyvinyl chloride plastisol, polyvinylidene chloride, and the like.



Application areas:

      Construction industry: production of exterior and interior products such as metal tiles, corrugated sheets, sandwich panels, profiles, metal ceilings, skirting boards, decorative panels in heated and non-heated rooms, lifts, window and door shutters, shelving, etc.

      Automotive industry: production of interior and exterior body parts (doors, boots, oil filters, instrument panels, windscreen wipers, etc.)

      Manufacture of household appliances, furniture and consumer goods: metal furniture, lighting fixtures, shelves, radiators, doors, boots, etc.


      PPGI is widely used in column and beam construction, civil engineering and decoration. Colored corrugated sheet is tough, useful and aesthetically pleasing. PPGI guarantees that buildings, automobiles and household appliances will retain their shine for years to come.



Coating Type

Polyester (PE) : Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.

Silicon modified polyester(SMP) : Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.

High Durability Polyester(HDP) : Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.

Polyvinylidene Fluoride(PVDF) : Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.



Standard JIS / EN / ASTM Standard
Grades SGCC / DX51D / S250GD
DX52D / DX53D / S280GD / S320GD / S350GD
Coating Primer: PU or Epoxy 5um
Top Coat : 15-20 um
Back Primer: PU or Epoxy
Back Coat: PE or Epoxy 5-12um
Spangle Regular spangle / Minimized spangle / Zero spangle
Sizes Thickness: 0.15mm-1.2mm Width: 900mm-1250mm
Delivery Condition 2/1, 2/2





Structural Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
30,33,36,40 0.25 0.9 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
36T2,45-80 0.25 1.35 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
45T2 .02- 0.08 .30- 1.0 .03- .07 0.025 .02- .08 0.6 0.2 0.2 0.15 0.06 0.008 0.008 0.025 .01- .03



HSLA Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
45C1 0.22 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
45C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C1 0.23 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C2 & 55C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
55C1 0.25 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C1 & 65C1 0.26 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C2 & 65C2 0.15 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
70C1 0.26 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005
70C2 0.15 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005



Common Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
CSA 0.1 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSB 0.02-.15 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSC 0.08 0.6 0.1 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
BH 0.012 1.5 0.12 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSA 0.1 0.5 0.02 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSB 0.02-.15 0.5 0.02 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
DDS 0.06 0.5 0.02 0.025 .01   0.2 0.2 0.15 0.06 0.008 0.008 0.025
EDDS 0.02 0.4 0.02 0.02 .01*   0.2 0.2 0.15 0.06 0.1 0.1 0.15

0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019 00.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019 1
0.8mm 1.0mm 1.5mm Color Coated Galvanized Steel Coil PPGI Steel PPGI Coils for Building Materials Zinc 80 Ral 9019 2
